Assembly and maintenance: diaphragm pump
Assembly and maintenance: diaphragm pump
SKU:MT183
Tiempo de despacho para este producto
Santiago:
Regiones:
Regiones extremas:
Región de Magallanes:
Lorem ipsum dolor
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Curabitur fringilla sapien risus, id semper tellus porta eu. Sed semper ante vel tellus pharetra, quis venenatis lorem elementum.
Descripción
Diaphragm pumps are a type of positive displacement pump that operates alternately with normal suction. They are suitable for transporting aggressive liquids such as acids, alkalis, radioactive, flammable, odorous and toxic liquids, provided they are manufactured from suitable materials. In addition, these pumps can run dry and are commonly used for volumetric dosing. The MT 183 kit is part of the GUNT Practice Line and is designed for assembly, maintenance and repair practices in technical schools and business training centres. It is ideal for complete, professionally oriented projects, encouraging both individual and small group work. With the MT 183, students can learn about the components and function of a typical diaphragm pump by systematically assembling and disassembling them.
Characteristics
- Diaphragm pump
- Flow rate: 0…2.4L/h
- Max lifting height: 100m
- Nominal stroke frequency at 50Hz: 156min-1
- Power consumption: max. 90W
- Suction/discharge connection: DN5 / DN5
- Pump materials
- Pump body: PP
- Double ball valves: PP-PRFV
- Valve balls: glass
- Valve seals: FPM
- Drive diaphragm: PTFE lined
- Dimensions and weights
Lxwxh: 690x360x312mm (tool box)
Weight: approx. 15kg
